拆卸自动变速箱前中后的大致过程

发布日期: 2023-06-13 来源: http://www.jnbsx.com/ 点击: 0

自动变速箱维修要根据车子的不同反应做出不同的对应措施。济南自动变速箱维修大致的维修过程为:
Automatic transmission maintenance requires different corresponding measures based on the different reactions of the car. The general maintenance process for Jinan automatic transmission maintenance is as follows:
1.拆卸自动变速箱前
Before disassembling the automatic transmission
在拆卸自动变速箱之前一定要查找库存是否有对应的自动变速箱型号,在不能保证起码的易损件和必换件都充沛的情况下,不建议立即拆卸解体。可先放干变速箱机油,卸下优盘,检车残油品种的杂质部分,在正常情况下,含有深褐色或喝死粉末为离合器片磨损,亮白色金属粉末为油泵、单向离合器、齿轮机构磨损,从而进一步判断车子的故障
Before disassembling an automatic transmission, it is important to check if there is a corresponding automatic transmission model in stock. It is not recommended to disassemble it immediately when there is no guarantee of sufficient vulnerable and replacement parts. You can first drain the transmission oil, remove the USB flash drive, and inspect the impurities in the residual oil of the vehicle. Under normal circumstances, if there is a dark brown or dead powder, it indicates the wear of the clutch plate, and if there is a bright white metal powder, it indicates the wear of the oil pump, one-way clutch, and gear mechanism, in order to further determine the fault of the vehicle
2.拆卸自动变速箱时
When disassembling the automatic transmission
因车身底板形状个位置的限制,直接从发动机后部拆下变速箱往往显得空间不够,可靠的办法是连同发动机一同从车上吊下。把自动变速箱拉离发动机时,应该沿着轴向拉动,克伴以绕轴线的顺和反方向转动,但不得上下左右摆动,以免损坏自动变速箱输入轴与液力耦合器或变矩器连接比分的表面状况与配合
Due to the limitations of the shape and position of the vehicle floor, directly removing the gearbox from the rear of the engine often appears to lack space. A reliable solution is to lift it together with the engine from the vehicle. When the automatic transmission is pulled away from the engine, it should be pulled along the axial direction, and the gear should rotate in the clockwise and reverse directions around the axis, but it should not swing up, down, left and right to avoid damaging the surface condition and matching of the connection ratio between the input shaft of the automatic transmission and the Fluid coupling or torque converter
济南自动变速箱维修
3.解体与装合自动变速箱
3. Disassembly and assembly of automatic transmission
先准备好工具及盛放各类零件的小盒子,在干净平整的操作台上进行解体,从前部油泵开始,从前后,由外向里逐步进行,并做好记录。在拆卸的时候,一定要记住不能用撬棍和铁器直接敲打,因自动变速箱壳体大多数用铝合金铸成。
Firstly, prepare tools and small boxes to hold various parts, and disassemble them on a clean and flat operating platform. Starting from the front oil pump, gradually proceed from the outside to the inside, and keep records. When disassembling, it is important to remember not to use crowbars and iron tools to directly strike, as most automatic transmission casings are made of aluminum alloy.
在拆卸液控阀体是防止上下阀体分离时滚珠、卡环等掉地,要准确记住正确位置,拆卸单向离合器要注意正确配装方向,装合时不能颠倒,零件拆卸后应用汽油洗净,确保各元件的清洁。如更换新离合器片、制动片应在变速箱油中浸泡,待吸足油后才能装合。
When disassembling the hydraulic control valve body, it is necessary to prevent the balls, snap rings, etc. from falling off the ground during the separation of the upper and lower valve bodies. The correct position should be accurately remembered. When disassembling the one-way clutch, attention should be paid to the correct assembly direction, and the assembly should not be reversed. After disassembling the parts, they should be cleaned with gasoline to ensure the cleanliness of all components. If replacing the clutch and brake pads with new ones, they should be soaked in transmission oil and can only be assembled after sufficient oil is absorbed.
另外一定要注意,装合时严格按照规定力矩拧紧螺钉自动变速箱出现故障大多数是由于车主使用不当造成的,如认为自动变速箱油不需要更换、自动变速箱进水不加以理会等。
In addition, it must be noted that the failure of the automatic transmission is mostly caused by the improper use of the owner when tightening the screws in strict accordance with the specified torque during assembly. For example, the owner thinks that the Automatic transmission fluid does not need to be replaced, and the automatic transmission does not pay attention to water ingress.
在平常行车中一定要正确使用车辆,一旦车子出现问题一定要及时送往公司进行检查维修,以免造成大患!更多相关事项就来我们网站http://www.jnbsx.com咨询!
It is important to use the vehicle correctly during normal driving. If there are any problems with the vehicle, it must be promptly sent to a professional company for inspection and repair to avoid causing major problems! For more related matters, come to our website http://www.jnbsx.com consulting service
